VL18-4P3940 SICK Cylindrical photoelectric sensors V18

VL18-4P3940 SICK Cylindrical photoelectric sensors V18

Be the first to review this product

Manufacturer: Sick

SKU: PCM1350

Old price: 145.00 (SAR)

Price: 64.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Features

Device type	Photoelectric sensors
Sensor/ detection principle	Photoelectric retro-reflective sensor
Dimensions (W x H x D)	18 mm x 18 mm x 75 mm
Housing design (light emission)	Cylindrical
Housing length	75 mm
Thread diameter (housing)	M18 x 1
Optical axis	Radial
Sensing range max.	0.05 m ... 3.7 m 1)
Sensing range	0.05 m ... 3 m 1)
Focus	Approx. 2.8°
Type of light	Visible red light
Light source	LED 2)
Light spot size (distance)	Ø 150 mm (3 m)
Angle of dispersion	Approx. 2.8°
Adjustment	Potentiometer, 270° (Sensitivity)

1) Reflector C110A.
2) Average service life: 100,000 h at TU = +25 °C.

Mechanics/electronics

Supply voltage	10 V DC ... 30 V DC 1)
Ripple	± 10 % 2)
Current consumption	30 mA 3)
Switching output	PNP 4)
Switching mode	Light/dark switching 4)
Switching mode selector	Selectable via L/D control cable
Output current Imax.	≤ 100 mA
Response time	≤ 2 ms 5)
Switching frequency	250 Hz 6)
Connection type	Male connector M12, 4-pin
Circuit protection	A 7) B 8) C 9) D 10)
Protection class	III
Weight	100 g
Polarisation filter	✔
Housing material	Plastic, PBT/PC
Optics material	Plastic, PMMA
Enclosure rating	IP67
Ambient operating temperature	–25 °C ... +70 °C
UL File No.	NMFT2.E175606

1) Limit values.
2) May not exceed or fall below Uv tolerances.
3) Without load.
4) Control wire open: dark switching D.ON.
5) Signal transit time with resistive load.
6) With light/dark ratio 1:1.
7) A = VS connections reverse-polarity protected.
8) B = inputs and output reverse-polarity protected.
9) C = interference suppression.
10) D = outputs overcurrent and short-circuit protected.
