Display method |
4-digit 11-segment LCD |
Control method |
ON/OFF control, P, PI, PD, PID control |
Input specification |
Thermocouple: K(CA), J(IC), T(CC), R(PR), S(PR), L(IC) RTD: DPt100?, Cu50℃ |
Sampling cycle |
50ms |
Control output |
Relay (250VAC~ 3A, 30VDC 3A) |
Option output |
Alarm 1/2, Transmission(DC4-20mA) |
Power supply |
100-240VAC~ 50/60Hz |
Protection structure |
IP50(front panel) |
Approval |
|
Display accuracy_RTD |
•At room temperature(23?±5?):(PV ±0.3% or ±1?, select the higher one) ±1-digit •Out of room temperature:(PV ±0.5% or ±2?, select the higher one) ±1-digit |
Display accuracy_Thermocouple |
•At room temperature(23?±5?):(PV ±0.3% or ±1?, select the higher one) ±1-digit •Out of room temperature:(PV ±0.5% or ±2?, select the higher one) ±1-digit |
Hysteresis(adjustable sensitivity) |
1 to 100℃/℉(0.1 to 50.0℃/℉) variable |
Proportional band |
0.1 to 999.9?/? |
Integral time |
0 to 9999 sec |
Derivative time |
0 to 9999 sec |
Control period |
0.5 to 120.0 sec |
Manual reset |
0.0 to 100.0% |
Environment_Ambient temperature |
-10 to 50℃, storage: -20 to 60℃ |
Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
Insulation type |
Double insulation (mark: , dielectric strength between primary circuit and secondary circuit: 3kV) |
Weight |
Approx. 146.1g(approx. 86.7g) |
