SV0370IS7-4NO LS Electric Drive Inverter SV0370IS74NO LS-iS7 Series

• Extended Product Type: Inverter
• Product ID: SV0370IS7-4NO
• LS Type Designation: Inverter

Variable Speed/Frequency Drive (VSD/VFD) / Inverter – LSIS (LS-iS7 series) – Input voltage 380Vac-480Vac (3-phase) (-15%…+10%) (400Vac / 415Vac / 440Vac) – Rated power 37kW / 50HP – Rated output current 91A (VT; normal duty) – Frequency (output) 0.01-400Hz – 3-phase 400V class – with RS-485 communication capability – NEMA 1

Specifications of LS SV0370IS7-4NO Drive Inverter LS-iS7 Series

• Input Voltage: 380-480V three phase +10%, -15% at 50/60Hz ±5%.
• Input Current: 69A at High Overload, 109A when Fan/Pump rated.
• Speed Control Range: 0-400Hz.
• Overload: 150% x 60 seconds, 200% for 2 seconds
• Dimension: 300mm Wide x 300.4mm Deep x 594mm high
• Supply voltage (AC): 380Vac-480Vac (3-phase) (-15%…+10%) (400Vac / 415Vac / 440Vac)
• Digital inputs: 4 x digital inputs (24Vdc; NPN/Sink or PNP/Source) (FX Forward; RX Reverse; BX Emergency stop; RST Reset)
• Digital outputs: 2 x digital inputs (Safe-Torque OFF STO A and B). 1 x digital output (SPDT Form-C NO/NC rly. contact; 1A at 250Vac/30Vdc). 1 x digital output (open-collector; 26Vdc; below 100mA)
• Analog inputs: 1 x analog input (-10…+10Vdc / 0-10Vdc / 0-20mA)
• Analog outputs:1 x  analog outputs (0-10Vdc / 0-20mA / 4-20mA
