S-N65CX AC200V MITSUBISH Contactor

Be the first to review this product

Manufacturer: Mitsubishi Electric

SKU: NSRN1319

Old price: 999.00 (SAR)

Price: 396.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Calculated data	Rated continuous current, A		100
	Rated power of three-phase motors, operating category AC-3	220-240 V kW (A)	18.5 (65)
		380-400 V kW (A)	30 (65)
		500 V kW (A)	37(60)
		690 V kW (A)	30 (38)
	Rated power of three-phase ohmic load, operational category 1 AC. T.	220-240 V kW (A)	35 (100)
		380-440 V kW (A)	65 (100)
		500-550 V kW (A)	85 (100)
		690 V kW (A)	100 (100)
		220-240 V kW	7.5
		380-440 V kW	eleven
		500-550 V kW	eleven
		690 V	eleven
	Maximum current for AC 4 AC. t. at 440 VA		47
	Rated current for non-ind. DC load current, category 1 post t. 100 switchings/h max. 500,000 cycles	48 VA	65
		110 VA	65
		220 VA	50
	Rated current for DC motors current category 2 and 4 post. t., 100 switching/h max. 500,000 cycles	48 VA	40
		110 VA	35
		220 VA	15
	Rated power 3-ph. capacitors, 15 switching/h max. 100,000 cycles*	220-240 V kvar	20
		380-440 V kvar	40
		550 V kvar	35
		690 V kvar	40
	Current; 3-ph., cosφ=0.35; 240/440 V	Switching current A	65/620
	Current; 3-ph., cosφ=0.35; 240/440 V	Tripping current A	650/620
	Nom. insulation voltage V		690
Electrical data	Coil power consumption (at rated voltage)	Peak when VA is turned on	132
		Long-term VA	17
		Watt W	2.8
	Switching frequency	Category 1 lane perch	1.200
		Category 2,3 per. t. per./h	1.200
		Category 4 lane perch	600
	Switching time (at rated voltage)	Closing ms	25
	Switching time (at rated voltage)	Opening ms	53
Mechanical data	Electrical life (category 3 AC) cycles (mil.)		1
	Mechanical cycle life (mil.)		5
	Cable cross-section (power contactor) mm²		2-25
	Cable cross-section (thermal protection relay) mm²		2-25
	Control terminals mm²		1-2.5
	Busbar connection width mm		-
	Built-in auxiliary contacts	Closing	2
	Built-in auxiliary contacts	Open	2
	Weight, kg		1.1
	Dimensions (WxHxD), mm		88x106x106
