Picture of RM17TG20 SCHNEIDER Phase supply control relay

RM17TG20 SCHNEIDER Phase supply control relay

Modular 3-phase supply control relay, 5 A, 2 CO, 208...440 V AC
Be the first to review this product
Manufacturer: Schneider
SKU: NSRN003
500.00 (SAR)
374.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Specifications

Main
Range of product Harmony Control Relays
Product or component type 3-phase control relay
Relay type Control relay
Product specific application For 3-phase supply
Relay name RM17TG
Relay monitored parameters Phase sequence
Phase failure detection (2 or more phase cut)
time delay Without
Switching capacity in VA 1250 VA
Measurement range 208...440 V voltage AC
Contacts type and composition 2 C/O
[Uc] control circuit voltage 208...440 V
Complementary
Maximum switching voltage 250 V AC
250 V DC
Minimum switching current 10 mA at 5 V DC
Supply voltage limits 183…484 V AC
Control circuit voltage limits - 12 % + 10 % Un
Power consumption in VA 0…22 VA at 400 V AC 50 Hz
Voltage detection threshold < 100 V AC
control circuit frequency 50...60 Hz +/- 10 %
Output contacts 2 C/O
Nominal output current 5 A
Measurement voltage limits 183…484 V AC
delay at power up 650 ms
Voltage range 183...484 V
Response time <= 130 ms (in the event of a fault)
Marking CE
Overvoltage category III conforming to IEC 60664-1
Insulation resistance > 500 MOhm at 500 V DC conforming to IEC 60255-5
> 500 MOhm at 500 V DC conforming to IEC 60664-1
[Ui] rated insulation voltage 400 V conforming to IEC 60664-1
Supply frequency 50/60 Hz +/- 10 %
Operating position Any position without derating
Connections - terminals Screw terminals, 1 x 0.5...1 x 4 mm² (AWG 20...AWG 11) solid without cable end
Screw terminals, 2 x 0.5...2 x 2.5 mm² (AWG 20...AWG 14) solid without cable end
Screw terminals, 1 x 0.2...1 x 2.5 mm² (AWG 24...AWG 12) flexible with cable end
Screw terminals, 2 x 0.2...2 x 1.5 mm² (AWG 24...AWG 16) flexible with cable end
Tightening torque 0.6…1 N.m conforming to IEC 60947-1
Housing material Self-extinguishing plastic
Local signalling LED (yellow) for relay ON
Mounting support 35 mm symmetrical DIN rail conforming to IEC 60715
Electrical durability 10000 cycles
Mechanical durability 30000000 cycles
Operating rate <= 360 operations/hour full load
Utilisation category AC-12 conforming to IEC 60947-5-1
AC-13 conforming to IEC 60947-5-1
AC-14 conforming to IEC 60947-5-1
AC-15 conforming to IEC 60947-5-1
DC-12 conforming to IEC 60947-5-1
DC-13 conforming to IEC 60947-5-1
Safety reliability data B10d = 850000
MTTFd = 924.6 years
Width 17.5 mm
Net weight 0.13 kg
