Picture of RHN412BEA76 SCHNEIDER Plug in relay

RHN412BEA76 SCHNEIDER Plug in relay

Plug in relay, Zelio Relay with suppressor, RHN, instantaneous, 4 C/O, 27 V DC, 5 A This plug-in relay reflects Schneider Electric expertise in relay since 1924 by helping to reduce the size of enclosuresand at the same time increase machine reliability. It has a large choice of number of contacts for high rated current use Its rated current is 5 A, is controlled with a 48 V DC circuit and has a latching of 4 C/O. They are intended for industrial machines, packaging, textile, HVAC, automation control panels, low/medium voltage switchgear, motor controls, PLC Interfaces, power supplies, building or medical equipment, lighting controls.
Be the first to review this product
Manufacturer: Schneider
SKU: NSRN014
Call for pricing
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Specifications

Main
Range of Product Harmony Relay
Product or Component Type Plug-in relay
Device short name RHN
Contacts type and composition 4 C/O
contact operation Standard
Instantaneous
[Uc] control circuit voltage 27 V DC
[Ithe] conventional enclosed thermal current 5 A 104 °F (40 °C)
Status LED Without
control type Manual control
Coil interference suppression With
Complementary
[Ui] Rated Insulation Voltage 250 V
Test levels Level A group mounting
Operating position Any position
Minimum switching capacity 150 mVA 10 mA
150 mVA, 1 V
Contact bounce time <= 10 ms
Maximum voltage drop <100 V for 3 A at 24 V
Average resistance 30 mOhm 68 °F (20 °C)
Average coil consumption 1.6 W 68 °F (20 °C)
Control circuit voltage limits 0.8...1.1 Uc IEC 60255
Drop-out voltage threshold 0.1...0.3 Uc
Time constant 12 ms open
15 ms closed
Mechanical durability 20000000 cycles
Maximum operating rate 6 cyc/mn
Operating time 1...4 ms energisation/de-energisation
1.2...4 ms de-energisation/energisation
10...20 ms between energisation of coil and closing of NO contact 68 °F (20 °C)
2...7 ms between de-energisation of coil and closing of NC contact 68 °F (20 °C)
CAD overall width 1.30 in (33 mm)
CAD overall height 1.69 in (43 mm)
CAD overall depth 2.13 in (54 mm)
Terminals description ISO n°1 (31-32-34)OC
(21-22-24)OC
(A1-A2)CO
(11-12-14)OC
(41-42-44)OC
Net Weight 0.20 lb(US) (0.09 kg)
Compatibility code RHN
