R422103562 AVENTICS 5/2-directional valve LS04-5/2SR-024DC-AF-I-M8-D6-NEW

AVENTICS™ 5/2-directional valve, Series LS04-AF R422103562

Manufacturer: AVENTICS

SKU: NSRN985

Old price: 1,560.00 (SAR)

Price: 1,082.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

il content of compressed air min. 0 mg/m³ Medium compressed air min. medium temperature -10 °c min. ambient temperature -10 °c connection type pipe connection pilot internal actuating control single solenoid electrical connection size m8 Manual override without detent dc operating voltage 24 v working pressure min. 3 bar switching principle 5/2 activation electrically max. particle size 5 µm max. medium temperature 50 °c max. ambient temperature 50 °c return with spring return valve type spool valve, positive overlapping Sealing principle soft seal electrical connection number of poles 3-pin electrical connection type plug voltage tolerance dc -10% / +10% working pressure max 7 bar compressed air connection output Ø 6 nominal flow qn 310 l/min

Product tags

Item	Unit Price	Unit Tax	Subtotal	Action
R422103562 AVENTICS 5/2-directional valve LS04-5/2SR-024DC-AF-I-M8-D6-NEW	1,082.00 (SAR)	162.30	1,244.30 (SAR)
			Shipping	0.00
			Total	1,244.30 (SAR)

Shipping Method

Full Name: *

Email: *

Country: *

Address 1:

Phone number:

il content of compressed air min.		0 mg/m³
Medium		compressed air
min. medium temperature		-10 °c
min. ambient temperature		-10 °c
connection type		pipe connection
pilot		internal
actuating control		single solenoid
electrical connection size		m8
Manual override		without detent
dc operating voltage		24 v
working pressure min.		3 bar
switching principle		5/2
activation		electrically

max. particle size		5 µm
max. medium temperature		50 °c
max. ambient temperature		50 °c
return		with spring return
valve type		spool valve, positive overlapping
Sealing principle		soft seal
electrical connection number of poles		3-pin
electrical connection type		plug
voltage tolerance dc		-10% / +10%
working pressure max		7 bar
compressed air connection output		Ø 6
nominal flow qn		310 l/min
