size |
Standard |
Nominal width [mm] |
13,0 |
Seal type on stud |
coating |
installation position |
arbitrary |
Packing size |
20 |
Construction set up |
Push-pull principle |
Operating pressure complete temperature range [bar] |
-0.95 to 6 |
Temperature depending operating pressure [bar] |
-0.95 to 14 |
Maritime classification |
see Certificate |
Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] Water according to manufacturer declaration at www.festo.com |
Information about operating and control medium |
Oiled operation possible |
Corrosion resistant class KBK |
1 - low corrosion stress |
ambient temperature [°C] |
-10 to 80 |
Product weight [g] |
79,0 |
Pneumatic connection 1 |
Male thread R1/2 |
Pneumatic connection 2 |
For hose exterior diameter 16 mm |
Sleeve colour |
blue |
Material information |
RoHs compliant |
Housing material |
PBT |
Sleeve material |
POM |
Tube seal, hose seal material |
NBR |
Hose clamping segment material |
High-alloyed stainless steels |
