Products tagged with 'auxiliary contact'

Eaton Auxiliary Contact - 1NC + 1NO, 2 Contact, Front Mount, 4 A ac, 10 A dc

range of product EZC250 EZCV250 range EasyPact device short name AL product or component type Switch device application Alarm range compatibility EZC circuit breaker EZCV circuit breaker signal contacts composition 1 NO/NC Complementary auxiliary contacts type Standard [Ith] conventional free air thermal current 5 A [Ie] rated operational current AC-12: 3 A at 250 V AC 50/60 Hz AC-12: 5 A at 125 V AC 50/60 Hz AC-12: 5 A at 24 V AC 50/60 Hz AC-12: 5 A at 48 V AC 50/60 Hz AC-15: 2 A at 250 V AC 50/60 Hz AC-15: 3 A at 125 V AC 50/60 Hz AC-15: 5 A at 24 V AC 50/60 Hz AC-15: 5 A at 48 V AC 50/60 Hz DC-12: 0.2 A at 250 V DC DC-12: 0.4 A at 125 V DC DC-12: 2.5 A at 48 V DC DC-12: 4 A at 24 V DC DC-14: 0.2 A at 250 V DC DC-14: 0.4 A at 125 V DC DC-14: 1 A at 48 V DC DC-14: 3 A at 24 V DC minimum load 10 mA at 24 V auxiliary connection terminal Lead wire

range of product EZC250 EZCV250 range EasyPact device short name AX product or component type Switch device application Signalling range compatibility EZC circuit breaker EZCV circuit breaker signal contacts composition 1 NO/NC Complementary auxiliary contacts type Standard [Ith] conventional free air thermal current 5 A [Ie] rated operational current AC-12: 3 A at 250 V AC 50/60 Hz AC-12: 5 A at 125 V AC 50/60 Hz AC-12: 5 A at 24 V AC 50/60 Hz AC-12: 5 A at 48 V AC 50/60 Hz AC-15: 2 A at 250 V AC 50/60 Hz AC-15: 3 A at 125 V AC 50/60 Hz AC-15: 5 A at 24 V AC 50/60 Hz AC-15: 5 A at 48 V AC 50/60 Hz DC-12: 0.2 A at 250 V DC DC-12: 0.4 A at 125 V DC DC-12: 2.5 A at 48 V DC DC-12: 4 A at 24 V DC DC-14: 0.2 A at 250 V DC DC-14: 0.4 A at 125 V DC DC-14: 1 A at 48 V DC DC-14: 3 A at 24 V DC minimum load 10 mA at 24 V auxiliary connection terminal Lead wire

TeSys GV3 - auxiliary contact - 1 NO + 1 NC early-break

TeSys GV3 - auxiliary contact- 1 NC early-break (fault)

TeSys GV auxiliary contact block, for motor circuit breakers GV2 and GV3. 1NO+1NC instantaneous auxiliary contacts. Rated for operation up to 2A/240V AC and 1A/60V DC. To be installed on front side of the circuit breaker, connection by screw clamp terminals. Sold in lots of 10 units. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
