PNP - PZ-V31P KEYENCE Square Reflective Cable Type, PNP

Model

PZ-V31P*1

Type

Intelligent reflective

Output

PNP

Detecting distance

5 to 300 mm (100 x 100 mmwhite mat paper)*2

Setting distance

40 to 300 mm (100 x 100 mmwhite mat paper)

Light source

Red LED

Sensitivity adjustment

Automatic push button

Response time

1 ms max.

Operation mode

LIGHT-ON/DARK-ON (switch-selectable)

Indicator lamp

―

Control output

100 mA (24 V) max., Residual voltage: 1 V max.

Digital monitor

7-segment, 3-digit red LED

Protection circuit

Reversed polarity, overcurrent protection, surge absorber

Rating

Power voltage

12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less

Power consumption

37 mA max.

Environmental resistance

Enclosure rating

IP67

Ambient light

Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max.

Ambient temperature

-20 to +55 °C (No freezing)

Relative humidity

35 to 85 % RH (No condensation)

Vibration resistance

10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions

Shock resistance

1,000 m/s2, 6 times in each of the X, Y, and Z directions

Case material

Glass-fibre reinforced plastic

Accessories

―

Weight

Approx. 55 g (including 2-m cable)
