PK6534 IFM Pressure switch with intuitive switch point setting PK-010-RFG14-HCPKG/US/ /W

Pressure switch with intuitive switch point setting; Operating voltage [V] : 9.6...32 DC; Min. insulation resistance [MΩ] : 100; (500 V DC); Protection class : III; Reverse polarity protection : yes; Total number of outputs : 2; Output signal : switching signal; Electrical design : PNP; Number of digital outputs : 2; Output function : complementary; Max. voltage drop switching output DC [V] : 2; Permanent current rating of switching output DC [mA] : 500; Switching frequency DC [Hz] : 100; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Measuring range : 0...10 bar: 0...1000 kPa: 0...1 MPa; Set point SP : 0.5...10 bar: 0.05...1 MPa; Reset point rP : 0.3...9.8 bar: 0.03...0.98 MPa; Switch point accuracy [% of the final value] : < ± 2,5; (Setting accuracy); Repeatability [% of the final value] : < ± 0,5; (with temperature fluctuations < 10 K); Characteristics deviation [% of the final value] : < ± 1,5 (BFSL) / < ± 2,5 (LS); (BFSL = Best Fit Straight Line; LS = limit value setting); Temperature drift per 10 K : < ± 0.5; Adjustment of the switch point : setting rings; Ambient temperature [°C] : -25...80; Storage temperature [°C] : -40...100; Materials : PBT; PC; FKM; stainless steel (1.4404 / 316L); Materials (wetted parts) : stainless steel (1.4404 / 316L); FKM; Min. pressure cycles : 50 million; Tightening torque [Nm] : 25; Process connection : threaded connection G 1/4 external thread internal thread:M5; Restrictor element integrated : no (can be retrofitted); With scale : yes

Connection

Connector: 1 x M12

No. of inputs/outputs

Number of digital outputs: 2

Current consumption

< 25 mA

Voltage supply

24 V

Display

operation: LED, green | switching status: LED, yellow

Degree of protection

IP 67

Weight

92.5 g

Dimensions

1136 x 50 x 60 mm
