CE certificate (see declaration of conformity) |
to EU low voltage directive |
Measured parameter |
Relative pressure |
Measurement process |
Pneumatic electric pressure converter |
Operating pressure [bar] |
1 to 10 |
Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
Medium temperature [°C] |
-20 to 80 |
ambient temperature [°C] |
-30 to 100 |
Switching element function |
changeover contact |
Max. switching frequency [Hz] |
3 |
Max. switch off voltage AC [V] |
250 |
Max. switch off voltage DC [V] |
250 |
Max. output current [mA] |
4.000 |
Electrical connection |
4 pin Plug |
Fastening type |
Screwable |
installation position |
arbitrary |
Pneumatic connection |
G1/4 |
Product weight [g] |
900 |
Housing material |
PA66-GF30 zinc-plated steel |
Settings range threshold value [bar] |
1 to 10 |
Protection category |
IP65 |
Diaphragm material |
NBR |
