P1NK202 WENGLOR Retro-Reflex Sensor

Optical Data Range 2,600 mm Reference Reflector/Reflector Foil RQ100BA Clear Glass Recognition yes Smallest Recognizable Part see Table 2 Switching Hysteresis < 5 % Light Source Red Light Polarization Filter yes Service Life (T = +25 °C) 100,000 h Max. Ambient Light 10,000 Lux Light Spot Diameter see Table 1 Single-Lens Optic yes
Manufacturer: Wenglor
SKU: NSRN240
2,000.00 (SAR)
1,313.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.



Optical Data

Range 2,600 mm
Reference Reflector/Reflector Foil RQ100BA
Clear Glass Recognition yes
Smallest Recognizable Part see Table 2
Switching Hysteresis  < 5 %
Light Source Red Light
Polarization Filter yes
Service Life (T = +25 °C) 100,000 h
Max. Ambient Light 10,000 Lux
Light Spot Diameter see Table 1
Single-Lens Optic yes






Electrical Data

Supply Voltage 10 ... 30 V DC
Supply Voltage with IO-Link 18 ... 30 V DC
Current Consumption (Ub = 24 V) < 20 mA
Switching Frequency 2,000 Hz
Switching frequency (speed mode) 3,500 Hz
Response Time 0.25 ms
Response time (speed mode) 0.14 ms
Temperature Drift < 3 %
Temperature Range -40 ... 60 °C
Switching Output Voltage Drop < 2 V
Switching Output/Switching Current 100 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Interface IO-Link V1.1
Protection Class III
