Picture of MEBH-5/2-1/8-B FESTO solenoid valve 173004

MEBH-5/2-1/8-B FESTO solenoid valve 173004

MEBH-5/2-1/8-B FESTO solenoid valve 173004
Be the first to review this product
Manufacturer: Festo
SKU: NSRN204
899.00 (SAR)
269.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Valve function 5/2 monostable
Actuation type Electrical
Build.width [mm] 17,8
Normal nominal flow [l/min] 600
Operating pressure [bar] 2.5 to 8
Construction set up Piston pusher
Reset mode Mechanical spring
Permission c UL us - Recognized (OL)
Protection category IP65
Nominal width [mm] 5
Pitch dimension [mm] 18
Exhaust function Can be throttled
Sealing principle Soft
installation position arbitrary
Hand assist actuation With Accessories ratcheting
Control type pilot operated
Control air supply Internal
Flow direction Not reversible
Überdeckung positive Überdeckung
b-value 0.36
C-value [l/sbar] 2,55
Shifting time off [ms] 28
Shifting time on [ms] 10
Power-on time 100 %
Coil characteristic value 24 V DC: 2,5 W
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Oscillation strength Transport use test with severity level 1 to FN 942017-4 and EN 60068-2-6
Shock resistance Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistant class KBK 2 - moderate corrosion stress
Bearing temperature [°C] -20 to 40
Medium temperature [°C] -5 to 50
Sound pressure level [dB(A)] 75
control medium Compressed air to ISO 8573-1:2010 [7:4:4]
ambient temperature [°C] -5 to 50
Product weight [g] 105
Electrical connection Wiring diagram Form C acc. to EN 175301-803
Plug
Square shape
acc. to EN 175301-803
Fastening type With throughway bores
Exhaust control connection 82/84 M5
Pneumatic connection 1 G1/8
Pneumatic connection 2 G1/8
Pneumatic connection 3 G1/8
Material information RoHs compliant
Seals material HNBR
NBR
Housing material Aluminium die casting
Control pressure [bar] 2.5 to 8
Pneumatic connection 4 G1/8
Pneumatic connection 5 G1/8
