Picture of MD3-320-65-A2-N Power Rectifier Diode Module

MD3-320-65-A2-N Power Rectifier Diode Module

MD3-320-65-A2-N Power Rectifier Diode Module Material Aluminium Part No MD3-320-52-A2-N
Be the first to review this product
SKU: NSRN1430
2,999.00 (SAR)
2,392.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Product Description

Maximum allowable average forward current (Case temperature) IF(AV) (TC) 320 А (100ºC) Repetitive pulsed reverse voltage; Repetitive pulsed closed state voltage VRRM/VDRM 6500 V Surge on-state current IFSM 6.0 kA Peak on-state voltage VFM 2.40 V Peak on-state current IFM 1570 A Threshold voltage V(TO) 0.95 V On-state slope resistance rT 1.100 mΩ Junction temperature Tj max 125 ºC Maximum case operating temperature Tc max 125 ºC Thermal resistance, junction to case Rth(j-c) 0.0680 ºC/W Electrical insulation strength VISOL 3.00 kV Design (switches) - dual component Type (circuit diagram) - diode-diode Connection diagram - half-bridge Weight W 1.5 kg Package - A2 Dimensions, mm L×B×H 124x60x52 mm Datasheet PDFSite source: MD3-320-65-A2 – Diode module 320A 4600V - 6500V – AS ENERGIhttps://asenergi.com/en/products/diode-modules-md3-md4-md5/md3-320-65-a2.html
