II5961 IFM Inductive sensors

housing: high-grade stainless steel, active face: LCP
Manufacturer: IFM
SKU: PCM054
1,899.00 (SAR)
1,755.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Inductive high-temperature sensor; Operating voltage [V] : 10...35 DC; Protection class : III; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally open; Max. voltage drop switching output DC [V] : 2; Permanent current rating of switching output DC [mA] : 150; Switching frequency DC [Hz] : 200; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Sensing range [mm] : 10; Operating distance [mm] : 0...8.1; Correction factor : steel: 1 / stainless steel: 0.6 / brass: 0.3 / aluminium: 0.2 / copper: 0.1; Hysteresis [% of Sr] : 3...15; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : 0...180; Housing : threaded type; Mounting : flush mountable; Thread designation : M30 x 1.5; Materials : housing: stainless steel; sensing face: LCP; Items supplied : lock nuts: 2
