H366R SWITCH FUSIBLE HD 600V 600A 3P NEMA3R

Main Product Single Throw Safety Switch Current Rating 600 A Certifications UL listed file E2875 Enclosure Rating NEMA 3R galvannealed steel Factory Installed Neutral None Disconnect Type Fusible disconnect Short Circuit Current Rating 10 kA H or K 200 kA R, J or L Mounting Type Surface Number of Poles 3 Electrical Connection Lugs Duty Rating Heavy duty Voltage Rating 600 V AC/DC Wire Size AWG 3/0...500 kcmil copper or aluminium Complementary width 708.15 mm (27.88 in) height 1277.87 mm (50.31 in) depth 257.30 mm (10.13 in) tightening torque 42.37 N.m (375 lbf.in) AWG 3/0...500 kcmil) Ordering and shipping details Category 00054 - H&HU SW,NEMA3R,400-1200A Discount Schedule DE1 GTIN 00785901452010 Returnability Yes Country of origin MX

Be the first to review this product

Manufacturer: Schneider

SKU: GND-004325

Vendor: MNPC

Old price: 6,900.00 (SAR)

Price: 6,550.00 (SAR)

Qty: GET A QUOTE FOR THIS
