Shape |
Square type |
Sensing method |
Diffuse-reflective |
Sensing distance |
White paper 100 x 100 mm: 100 mm |
Differential distance |
20% max. of sensing distance |
Light source |
Infrared LED (870 nm) |
Power supply voltage |
12 to 24 VDC±10% ripple (p-p) 10% max. |
Current consumption |
30 mA max. |
Control output |
PNP open collector 26.4 VDC max. 100 mA max. Residual voltage: 1 V max. (Load current Less than 10 mA) Residual voltage: 2 V max. (Load current 10 to 100 mA) |
Operation mode |
Light-ON/Dark-ON selectable |
Protective circuit |
Output short-circuit protection, Output reverse polarity protection, Power supply reverse polarity protection |
Response time |
Operate or reset: 1 ms max. |
Sensitivity setting |
Single-turn adjustment |
Ambient illuminance |
Incandescent lamp: 3,000 lx max. Sunlight: 10,000 lx max. |
Ambient temperature range (Operating) |
-25 to 55 ℃ (with no icing) |
Ambient temperature range (Storage) |
-40 to 70 ℃ (with no freezing or condensation) |
Ambient humidity range (Operating) |
35 to 85 % (with no condensation) |
Ambient humidity range (Strage) |
35 to 95 % (with no condensation) |
Insulation resistance |
20 MΩ min. (500 VDC megger) |
Dielectric strength |
1000 VAC 50/60 Hz 1 min |
Vibration resistance |
Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h |
Shock resistance |
Destruction: 500 m/s2 3 times each in X, Y and Z directions |
Degree of protection |
IEC: IP67 |
Connection method |
Pre-wired models (Cable length 2 m) |
Indicator |
Operation indicator (orange), Stability indicator (green) |
Weight |
Package: Approx. 65 g |
Accessories |
Instruction manual |
Material |
Case: Polybutylene terephthalate (PBT) Lens: Denatured Polyarylate
|
