Stroke [mm] |
25 |
Piston diameter |
32 mm |
Piston rod thread |
M10x1,25 |
Dampening |
PPV: Pneumatic dampening both sides adjustable |
installation position |
arbitrary |
Construction set up |
Piston piston rod cylinder tube |
Position detection |
For proximity switch |
Operating pressure [bar] |
1 to 10 |
Principle of operation |
double acting |
Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
Information about operating and control medium |
Oiled operation possible (required in further operations) |
Corrosion resistant class KBK |
2 - moderate corrosion stress |
ambient temperature [°C] |
-20 to 80 |
Theoretical force at 6 bar, Return flow [N] |
415,0 |
Fastening type |
With Accessories |
Pneumatic connection |
G1/8 |
Material information |
RoHs compliant |
Cover material |
Aluminium wrought alloy |
Seals material |
NBR TPE-U(PU) |
Piston rod material |
High-alloyed steel |
Cylinder tube material |
High-alloyed stainless steels |
Theoretical force at 6 bar, flow [N] |
482,5 |
Dampening length [mm] |
14 |
Moving mass [g] |
144 |
Product weight [g] |
410 |
