DNC-50-420-PPV-A FESTO ISO cylinder 163368

Pneumatic connection G1/4 Stroke 2 mm Operating Pressure 0,6 bar ... 12 bar Mounting Position optional Weight 1,260g

SKU: NSRN186

Old price: 1,000.00 (SAR)

Price: 714.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Stroke		2 mm ... 2.000 mm
Material piston rod		High-alloy steel
Material cover		Die-cast aluminium Coated
Pneumatic connection		G1/4
Additional weight per 10 mm stroke		64 g
Additional moving mass per 10 mm stroke		25 g
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke		1.178 N
Cushioning length		22 mm
Ambient temperature		-20 °C ... 80 °C
Note on operating and pilot medium		Lubricated operation possible (in which case lubricated operation will always be required)
Mode of operation		Double-acting
Variants		Piston rod at one end
Position detection		Via proximity switch
Piston-rod end		Male thread
Mounting position		optional
Piston rod thread		M16x1.5

Material cylinder barrel		Wrought aluminium alloy Smooth anodised
Material seals		TPE-U(PU)
Note on materials		RoHS-compliant
Type of mounting		Via female thread With accessories
Basic weight for 0 mm stroke		1.260 g
Moving mass for 0 mm stroke		538 g
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke		990 N
Impact energy in end positions		0,2 J
Corrosion resistance class CRC		2 - Moderate corrosion stress
Operating medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Operating pressure		0,6 bar ... 12 bar
Symbol		00991235
Design		Piston Piston rod Profile barrel
Conforms to standard		ISO 15552
Cushioning		Pneumatic cushioning, adjustable at both ends
Piston diameter		50 mm
