Material cylinder barrel |
|
Wrought aluminium alloy Smooth anodised |
|
Material piston rod |
|
High-alloy stainless steel |
|
Material cover |
|
Wrought aluminium alloy Anodised |
|
Note on materials |
|
RoHS-compliant |
|
Type of mounting |
|
With through-hole Via female thread With accessories Either: |
|
Permissible lateral force during switching operation |
|
595 N |
|
Ambient temperature |
|
-10 °C ... 80 °C |
|
Corrosion resistance class CRC |
|
2 - Moderate corrosion stress |
|
Operating medium |
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Protection against torque/guide |
|
Round piston rod |
|
Position detection |
|
Via proximity switch |
|
Mode of operation |
|
Single-acting Pulling |
|
Cushioning |
|
Elastic cushioning rings/plates at both ends |
|
Stroke |
|
25 mm |
|
