Picture of DC1-345D8FB-A20CE1 EATON Variable frequency drive 185752

DC1-345D8FB-A20CE1 EATON Variable frequency drive 185752

Eaton DC-1 Drive, IP20 480V IN/460V Out 3HP, 5.8A, Rfi Enh Fw
Be the first to review this product
Manufacturer: Schneider
SKU: NSRN018
3,500.00 (SAR)
2,911.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

General specifications
Product name
Eaton DC1 Variable frequency drive
Part no.
DC1-345D8FB-A20CE1
EAN
4015081812516
Product Length/Depth
152 millimetre
Product height
231 millimetre
Product width
107 millimetre
Product weight
2 kilogram
Certifications
CSA-C22.2 No. 14
Certified by UL for use in Canada
UL Category Control No.: NMMS, NMMS7
UL File No.: E172143
CUL
RCM
UL 508C
RoHS, ISO 9001
Specification for general requirements: IEC/EN 61800-2
Safety requirements: IEC/EN 61800-5-1
IEC/EN61800-3
UkrSEPRO
IEC/EN 61800-3
CE
IEC/EN61800-5
UL
UL report applies to both US and Canada
EAC
Product Tradename
DC1
Product Type
Variable frequency drive
Product Sub Type
None
Catalog Notes
Environmental class: 3C2, 3S2
Overload cycle for 60 s every 600 s
Features & Functions
Features
Parameterization: drivesConnect
Parameterization: drivesConnect mobile (App)
Parameterization: Fieldbus
Parameterization: Keypad
Fitted with:
7-digital display assembly
Brake chopper
Internal DC link
PC connection
Control unit
IGBT inverter
Radio interference suppression filter
Breaking resistance
Additional PCB protection
Functions
4-quadrant operation possible
General information
Cable length
C2 ≤ 5 m, Radio interference level, maximum motor cable length
100 m, screened, maximum permissible, Motor feeder
200 m, screened, with motor choke, maximum permissible, Motor feeder
300 m, unscreened, with motor choke, maximum permissible, Motor feeder
150 m, unscreened, maximum permissible, Motor feeder
C3 ≤ 25 m, Radio interference level, maximum motor cable length
Communication interface
SmartWire-DT, optional
OP-Bus (RS485), built in
Modbus RTU, built in
CANopen®, built in
Connection to SmartWire-DT
Yes
In conjunction with DX-NET-SWD3 SmartWire DT module
Degree of protection
IP20
NEMA Other
Electromagnetic compatibility
1st and 2nd environments (according to EN 61800-3)
Frame size
FS2
Mounting position
Vertical
Product category
Variable frequency drives
Protection
Finger and back-of-hand proof, Protection against direct contact (BGV A3, VBG4)
Protocol
CAN
EtherNet/IP
MODBUS
Other bus systems
Radio interference class
C2, C3: depending on the motor cable length, the connected load, and ambient conditions. External radio interference suppression filters (optional) may be necessary.
Optional external radio interference suppression filter for longer motor cable lengths and for use in different EMC environments
