Drive control method |
Closed loop V/f, Closed loop vector, Open loop V/f, Open loop vector |
Drive supply voltage |
400 V three phase |
Max. motor output at constant torque (HD) |
1.5 kW |
Max. motor output at variable torque (ND) |
2.2 kW |
Built in EMC filter |
|
Degree of protection (IP) |
IP20 |
Finless type |
|
Compatible motor type |
Induction or asynchronous motor, Permanent magnet motor |
Regenerative solutions |
As inverter option |
Communication port(s) |
MODBUS Slave, Serial RS-422, Serial RS-485 |
Communication option(s) |
CANopen, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, MECHATROLINK II Slave, MODBUS/TCP, POWERLINK, PROFIBUS DP Slave, PROFINET Slave |
Product Height (unpacked) |
260 mm |
Product Width (unpacked) |
140 mm |
Product Depth (unpacked) |
147 mm |
Product Weight (unpacked) |
3200 g |
