Picture of CCT15482 Schneider Electric Twilight switch for distribution board

CCT15482 Schneider Electric Twilight switch for distribution board

CCT15482 Schneider Electric Twilight switch for distribution board Schneider Electric Twilight switch for distribution board Acti 9 IC100 (2 - 100 lux) twilight switch
Be the first to review this product
Manufacturer: Schneider
SKU: PCM1345
565.00 (SAR)
497.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Datasheet

Rated voltage (V)
230
Rated frequency (Hz)
50 - 60
Max. incandescent lamp load (W)
2600
Max. load fluorescent lamp (VA)
2300
Max. load fluorescent lamp (Duo circuit) (VA)
2300
Max. load fluorescent lamp (parallel compensated) (VA)
730
Max. switching current (cos phi = 0.6) (A)
10
Rated switch current (A)
16
Adjustment range brightness value (lx)
2 - 100
With programmable overnight shutoff
No
Push button input
No
Max. conductor length light sensor (m)
50
Protection class light sensor
II
Mounting method light sensor
Wall surface mounted
Mounting method
DIN rail
Width in number of modular spacings
1
Built-in depth (mm)
67
Degree of protection (IP)
IP20
Degree of protection (IP) light sensor
IP55
