ACS880-01-07A6-5 ABB PN: 4.0 kW, IN: 7.6 A Variable Frequency Drive
ABB ACS880-01-07A6-5, ACS880, 5HP, 3 Phase, 380-480V, Nema 1 Enclosure, Variable Frequency Drive is available to buy in increments of 1
9,875.00 (SAR)
6,061.00 (SAR)
The ACS880-01 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps and fans.
The ACS880-01 comes in one compact package for easy installation and commissioning. The drive can be installed on the wall as standard and in a cabinet as an option. The drive offering includes enclosure classes up to IP55, making it suitable for most environments and installations. ACS880-01 drives have all the essential features built-in. These features include as standard a choke for harmonic filtering as well as options like a brake chopper, EMC filter and communication protocol adapter, functional safety, external output filters and I/O extension modules.
Specifications
Manufacturer Part Number |
ACS880-01-07A6-5 |
Item Number |
ACS880-01-07A6-5 |
Manufacturer |
ABB |
Product Series |
ACS880 |
Family Series |
ABB Drives, ACS880 Series |
Input Phase |
3 |
HP (Constant Torque Rating) |
3 hp |
HP (Variable Torque Rating) |
5 hp |
Amps (Constant Torque Rating) |
5.2 A |
Amps (Variable Torque Rating) |
7.6 A |
Braking Type |
DC Injection, Dynamic Braking, Flux Braking |
Closed Loop |
Optional |
AC Line Regenerative |
No |
Operator Controls |
Keypad Included |
IP Rating |
IP21 |
Motor Control-Max Level |
Direct Torque Control |
Mounting |
Panel |
Input Range Voltage (AC) |
380-500 VAC |
Max Frequency |
500 Hz |
Package |
ACS880R1IP21 |
Frame Size |
R1 |
Enclosure |
R1 |
Dynamic Braking Trans |
Included |
Comments |
Includes Safe Torque Off, Removable Memory Unit And Customizable Keypad With Startup Assistant. |
Net Weight |
14.37 lbs |
Gross Weight |
18.25 lbs |
