Picture of ABLS1A24050 SCHNEIDER Regulated Power Supply

ABLS1A24050 SCHNEIDER Regulated Power Supply

Regulated Power Supply, 100-240V AC, 24V 5 A, single phase, Optimized
Be the first to review this product
Manufacturer: Schneider
SKU: NSRN645
1,000.00 (SAR)
574.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Specifications

Main
range of product Modicon Power Supply
Product or component typee Power supply
Power supply type Regulated switch mode
Variant option Optimized
Enclosure material Aluminium
Nominal input voltage 100...240 V AC single phase
100...240 V AC phase to phase
140...340 V DC
Rated power in W 120 W
Output voltage 24 V DC
Power supply output current 5 A
Complementary
Input voltage limits 85...264 V AC without temperature derating
120...375 V DC without temperature derating
85…120 V DC with temperature derating
Nominal network frequency 50…60 Hz
Network system compatibility TN
TT
IT
Maximum leakage current 1 mA 240 V AC
Input protection type Integrated fuse (not interchangeable) 4 A
External protection (recommended) 20 A Curve C
External protection (recommended) 13 A Curve C
Inrush current 30.0 A at 115 V
60.0 A at 230 V
Power factor 0.55 at 115 V AC
0.45 at 230 V AC
Efficiency 85 % at 115 V AC
88 % at 230 V AC
Output voltage adjustment 22...28 V
Power dissipation in W 25 W
Current consumption < 2.5 A 115 V AC
< 1.4 A 230 V AC
< 1.3 A 140 V DC
Turn-on time < 1 s
Holding time > 20 ms 115 V AC
> 40 ms 230 V AC
Startup with capacitive loads 8000 µF
Residual ripple < 120 mV
Meantime between failure [MTBF] 700000 h at 25 °C, full load conforming to SR 332
Output protection type Against overload and short-circuits, protection technology: automatic reset
Against over temperature, protection technology: manual reset
Against overvoltage, protection technology: manual reset
Connections - terminals Screw connection: 0.5...4 mm², (AWG 20...AWG 12) without wire end ferrule for output
Screw connection: 0.5...2.5 mm², (AWG 20...AWG 14) with wire end ferrule for output
Screw connection: 0.75...4 mm², (AWG 18...AWG 12) without wire end ferrule for input
Screw connection: 0.75...4 mm², (AWG 18...AWG 12) with wire end ferrule for input
Line and load regulation < 0.5 % at 0 to 100 % load at 25 °C
< 1 % at full voltage range in line at 25 °C
Status LED 1 LED (green) output voltage
Depth 117.6 mm
height 123.6 mm
Width 40 mm
Net weight 0.55 kg
Output coupling Parallel
Serial
Mounting support Top hat type TH35-15 rail conforming to IEC 60715
Top hat type TH35-7.5 rail conforming to IEC 60715
Double-profile DIN rail
Supply SELV conforming to IEC 60950-1
SELV conforming to IEC 60204-1
SELV conforming to IEC 60364-4-41
Dielectric strength 3000 V AC with input to output

Overvoltage category II
