Signal type |
Voltage |
Signal type (voltage) |
24 VDC |
Supply voltage (system) |
24 VDC (-25 … +30 %); Via pluggable connector (CAGE CLAMP® connection); External backup fuse required: 2 A (time delay) |
Supply voltage (field) |
24 VDC (-25 … +30 %); Via power jumper contacts (power supply via CAGE CLAMP® connection; transmission via spring contact); External backup fuse required: 2 A (time delay) |
Indicators |
LED (A, B) green: operating voltage status: system, power jumper contacts |
Number of outgoing power jumper contacts |
2 |
Current carrying capacity (power jumper contacts) |
10A |
Current via system voltage (max.) |
1.5 A (1 A up to hardware version 04) |
