  • 59836 SCHNEIDER base unit SEP363 for Sepam series 60 - 24…250 V - with advanced UMI
Picture of 59836 SCHNEIDER base unit SEP363 for Sepam series 60 - 24…250 V - with advanced UMI

59836 SCHNEIDER base unit SEP363 for Sepam series 60 - 24…250 V - with advanced UMI

59836 SCHNEIDER base unit SEP363 for Sepam series 60, 24... 250 V with advanced UMI
Be the first to review this product
Manufacturer: Schneider
SKU: NSRN1090
26,666.00 (SAR)
21,384.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Specifications

Main
Range of produc Sepam series 60
Device short name SEP363
User machine interface type Advanced
Complementary
UMI indication Alarms and operating messages
Version of Sepam and remote modules
Status of logic inputs
Main protection settings
Metering and diagnosis data
List of activated protection functions
UMI control Sepam reset
Output testing
Alarm acknowledgement
Display resolution 128 x 64 pixels
number of key 9
Local signalling 2 LEDs for Sepam operating status (back part)
2 LEDs for Sepam operating status (front face)
9 LEDs for indication of parameters (front face)
Output type Annunciation relay: 100...240 V AC 47.5...63 Hz continuous current: 2 A breaking capacity: 1 A cos φ > 0.3
Annunciation relay: 127 V DC continuous current: 2 A breaking capacity: 0.5 A L/R < 20 ms
Annunciation relay: 220 V DC continuous current: 2 A breaking capacity: 0.15 A L/R < 20 ms
Annunciation relay: 24 V DC continuous current: 2 A breaking capacity: 2 A L/R < 20 ms
Annunciation relay: 48 V DC continuous current: 2 A breaking capacity: 1 A L/R < 20 ms
Control relay: 100...240 V AC 47.5...63 Hz continuous current: 8 A breaking capacity: 5 A cos φ > 0.3 making capacity: < 15 A for 200 ms
Control relay: 100...240 V AC 47.5...63 Hz continuous current: 8 A breaking capacity: 8 A resistive making capacity: < 15 A for 200 ms
Control relay: 127 V DC continuous current: 8 A breaking capacity: 0.2 A L/R < 40 ms making capacity: < 15 A for 200 ms
Control relay: 127 V DC continuous current: 8 A breaking capacity: 0.5 A L/R < 20 ms making capacity: < 15 A for 200 ms
Control relay: 127 V DC continuous current: 8 A breaking capacity: 0.7 A resistive making capacity: < 15 A for 200 ms
Control relay: 220 V DC continuous current: 8 A breaking capacity: 0.1 A L/R < 40 ms making capacity: < 15 A for 200 ms
Control relay: 220 V DC continuous current: 8 A breaking capacity: 0.2 A L/R < 20 ms making capacity: < 15 A for 200 ms
Control relay: 220 V DC continuous current: 8 A breaking capacity: 0.3 A resistive making capacity: < 15 A for 200 ms
Control relay: 24 V DC continuous current: 8 A breaking capacity: 4 A L/R < 40 ms making capacity: < 15 A for 200 ms
Control relay: 24 V DC continuous current: 8 A breaking capacity: 6 A L/R < 20 ms making capacity: < 15 A for 200 ms
Control relay: 24 V DC continuous current: 8 A breaking capacity: 8 A resistive making capacity: < 15 A for 200 ms
Control relay: 48 V DC continuous current: 8 A breaking capacity: 1 A L/R < 40 ms making capacity: < 15 A for 200 ms
Control relay: 48 V DC continuous current: 8 A breaking capacity: 2 A L/R < 20 ms making capacity: < 15 A for 200 ms
Control relay: 48 V DC continuous current: 8 A breaking capacity: 4 A resistive making capacity: < 15 A for 200 ms
[Us] rated supply voltage 24/250 V DC tolerance: - 20...10 % maximum consumption: < 16 W
Supply inrush current < 10 A for 10 ms at 24/250 V DC
Battery type Lithium 3.6 V size: 1/2 AA
Battery life 10 year(s) (Sepam energized)
8 year(s) (Sepam not energized)
Mounting mode Fixed
mounting support Plate
