Picture of 2CDA282799R0041 ABB M202-4A Miniature Circuit Breaker - 2P - 4 A

2CDA282799R0041 ABB M202-4A Miniature Circuit Breaker - 2P - 4 A

2CDA282799R0041 ABB M202-4A Miniature circuit breaker - 2P - 4 A.
Be the first to review this product
Manufacturer: ABB
SKU: NSRN786
450.00 (SAR)
231.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Standards:
IEC/EN 60947-2
Rated Operational Voltage:
acc. to IEC 60898-1 230 V
acc. to IEC 60947-2 400 V AC
Rated Insulation Voltage (Ui):
acc. to IEC/EN 60664-1 440 V
Rated Impulse Withstand Voltage (Uimp):
4 kV
at 2000 m 5 kV
at Sea Level 6.2 kV
Input Voltage Type:
AC
Rated Current (In):
4 A
Rated Short-Circuit Capacity:
(230 V AC) 12.5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(400 V AC) 25 kA
(400 V) 6 kA
Rated Conditional Short-Circuit Current (Inc):
(230 V) 25 kA
Rated Service Short-Circuit Breaking Capacity (Ics):
(230 V AC) 12.5 kA
(400 V AC) 12.5 kA
Rated Frequency (f):
50 / 60 Hz
Power Loss:
3.4 W
at Rated Operating Conditions per Pole 1.7 W
Power Supply Connection:
Arbitrary
Contact Position Indication:
Red ON / Green OFF
Energy Limiting Class:
3
Mechanical Endurance:
20000 cycle
Number of Protected Poles:
2
Number of Poles:
2
Overvoltage Category:
III
Tightening Torque:
2.8 N·m
Screw Terminal Type:
Failsafe Bi-directional Cylinder-lift Terminal
Actuator Marking:
I / O
Actuator Material:
Insulation Group II, Black, Sealable
Housing Material:
Insulation Group I, RAL 7035
Options Provided:
Magnetic only protection
Mounting on DIN Rail:
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Mounting Position:
any
Recommended Screw Driver:
Pozidriv 2
Accessories Available:
Yes
Connecting Capacity:
Busbar 10 / 10 mm²
Flexible with Ferrule 0.75 ... 16 mm²
Flexible 0.75 ... 16 mm²
Rigid 0.75 ... 25 mm²
Stranded 0.75 ... 25 mm²
Installation Size:
acc. to DIN 43880 1
Terminal Type:
Screw Terminals
