1SBL411024R8000 ABB UA75-30-00RA 220-230V 50Hz / 230-240V 60Hz

The UA75-30-00RA 220-230V 50Hz / 230-240V 60Hz is a 3-pole contactor for capacitor switching and can be used in installations in which the peak current far exceeds 100 times the nominal rms current. The contactors are delivered complete with their damping resistors and must be used without additional inductances (see table below). The capacitors must be discharged (maximum residual voltage at terminals ≤ 50 V) before being re-energized when the contactors are making. Their electrical durability is 250 000 operating cycles for Ue < 500 V and 100 000 operating cycles for 500 V ≤ Ue ≤ 690 V. The UA..RA contactors are fitted with a special front-mounted block, which ensures the serial insertion of 3 damping resistors into the circuit to limit the current peak on energization of the capacitor bank. Their connection also ensures capacitor precharging in order to limit the second current peak occurring upon making the main poles. The insertion of resistors allows to damp the highest current peak of the capacitor when switching on, whatever its level. The UA..RA series 3-pole contactors are of the block type design. Main poles: 3 main poles Control circuit: AC operated with laminated magnet circuit - Accessories:
