1SBL371001R8411 ABB Contactor

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.

Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.

100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Rated current

115A (690Vac; 40°C; AC-1)
95A (690Vac; 55°C; AC-1)
80A (690Vac; 70°C; AC-1)
65A (220-440Vac; 55°C; AC-3)
55A (500Vac; 55°C; AC-3)
43A (690Vac; 55°C; AC-3)
25A (1000Vac; 55°C; AC-3)
68A (maximum mot. switching current)

Rated active power (kW)

18.5kW (220-240Vac; AC-3)
30kW (380-400Vac; AC-3)
37kW (415-690Vac; AC-3)

Rated operating voltage (Ue)

690 V

Rated impulse voltage (Uimp)

8 kV

Rated insulation voltage (Ui)

(IEC/VDE) 1000 V
(UL/CSA) 600 V

Connection type

Screw-clamp connections

Control Voltage (AC)

110Vac (50Hz)
110Vac-120Vac (60Hz)

Mounting mode

Mounting on plate

Normally Open (NO) auxliary contacts

1 NO contacts

Normally Closed (NC) auxiliary contacts

1 NC contacts

Net Height (mm)

110 mm

Net Width (mm)

82 mm

Net Depth (mm)

108 mm

Application type

Direct On Line (DOL)
FVNR (Full-Voltage Non-Rv.)

Order code / Manufacturer SKU

A63-30-11-84

Manufacturer product status

Commercialized

Equivalent to

A63301184

UPC code

66201988056

UNSPSC code

39121529

Compliant with standard(s)

IEC/EN 60947-1
IEC/EN 60947-4-1
IEC/EN 60529

Benefits

A-line contactors (9...300)
- 3- & 4-pole contactors
- General purpose up to 400 A
- Motor applications up to 300 HP / 250 kW
- NEMA Sizes 00...5
- Additional ratings including definite purpose & elevator duty
- AC or DC coil input voltages

Operating rate

(at no load) 3600 Cycles/hour
(AC-1) 600 Cycles/hour
(AC-3) 600 Cycles/hour
(AC-2 / AC-4) 150 Cycles/hour
