1SAM340000R1007 ABB MS132-2.5T Circuit Breaker for Primary Transformer Protection 1.6 ... 2.5 A

The circuit breaker for transformer protection, MS132-2.5T, is a compact 45-mm-wide device designed to protect control transformers on the primary side. This device has a rated operational current of Ie = 2.5 A. It allows fuse-less protection against overload and short-circuit. The short-circuit current setting is fixed to 20 times the rated operational current to handle the high inrush current generated by transformers. The device allows you to manually connect and disconnect the transformer from the mains thanks to its built-in disconnection function. The circuit breaker for transformer protection offers a rated service short-circuit breaking capacity of Ics = 100 kA at 400 VAC and a trip class of 10. Further features are temperature compensation, a trip-free mechanism, a rotary handle with a clear switch position indication, and a short-circuit trip indicator. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, power in-feed blocks, and terminal spacers are available as accessories.
