17F5C1G-350A KEB power supply

KEB Combivert F5 Basic is meant for standard devices for controlled tasks with rated power of 0.37 to 15 kW. From simple to sophisticated - in open-loop tasks throughout the engineering sector.

• connection 1-/3-phase 230 V and 3-phase 400 V, choice of AC or DC supply in one unit
• optimized KEB-SMM control algorithm (sensorless motor management)
• 17 pluggable control terminals, PNP-logic
• analog input 0 … 10 V, ±10 V, 0 / 4 … 20 mA (housing D, E)
• programmable analog output 0 … ±10 V
• 5 programmable digital inputs
• 2 programmable relay outputs
• 4 programmable software inputs/outputs
• 8 free-to-program parameter sets including S-curves, ramp stop, power off -function, DC-braking, PID controller, electronic motor protection, brake control, internal timer, counter input, energy saving function
• output frequencies up to 1600 Hz, output voltage control, adjustable switching frequencies up to 16 kHz
• controlled positioning to end position/counter pulse
• high-dynamic scanning of the control terminals and the serial interface in 2 ms
• ± DC-link connection, internal braking chopper GTR7, motor-PTC evaluation,
• integrated filter to EN 55011/C1 (option: B-, D-, E-housing)
