Picture of 1783-MS10T ALLAN BRADLEY 10 port Switch

1783-MS10T ALLAN BRADLEY 10 port Switch

The 1783-MS10T switch is a Stratix 8000 managed switch. It comes with up to 8 Ethernet copper ports and 2 combo ports.
Be the first to review this product
Manufacturer: Allen-Bradley
SKU: NSRN607
6,423.00 (SAR)
5,937.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Mechanical

Width 15.3 cm
Height 14.8 cm
Depth 11.75 cm
Screw torque, power and alarm terminals 0.23 Nm



Electrical

Layer 2 Yes
Layer 3 No
Manageable Yes
Power dissipation 15.7 W
Power consumption, maximum (expansion module power not included) 15.7 W
Total number of ports 10
Wire size, ethernet connection RJ45 connector according to IEC 60603-7, 2 or 4-pair category 5e minimum cable according to TIA 568-B.1 or category 5 cable according to ISO/IEC 24702
Ethernet Yes
Protection type—Electronic S (short time trip units) Panel mount
Alarm relay, CL 2/SELV at 30 V DC, maximum 1 A
Inrush current, maximum 2 A
Isolation voltage (continuous), basic insulation type, power to ground, power to network channels, and power to alarm 75 V
Maximum insulation, DC power and alarm connections 1.2 mm
Oscillatory surge withstand IEEE C37.90.1 2.5 kV
Switch input, CL 2/SELV at 18 - 60 V DC, maximum 2 A
Wire size, DC power and alarm connections, solid or stranded copper wire rated at 90 °C or greater 0.5 mm²
Wire size, ground connection, solid or stranded copper wire rated at 75 °C or greater 3.3 mm²
Wiring category on alarm ports 2
Wiring category on Ethernet ports 2
Wiring category on power ports 2



Environmental

Degree of protection (IP) IP20
Housing base material Open-style
Nominal position T4
Temperature, surrounding air, maximum 60 °C
EFT/B immunity for IEC 61000-4-4 at 5 kHz on alarm ports ±2 kV
EFT/B immunity for IEC 61000-4-4 at 5 kHz on Ethernet ports ±2 kV
Emissions, CISPR11 (IEC 61000-6-4) Class A
ESD immunity, IEC 61000-4-2, air discharges 15 kV
ESD immunity, IEC 61000-4-2, contact discharges 8 kV
Radiated RF immunity, IEC 61000-4-3 with 1 kHz sine-wave 80% AM from 1000 - 2700 MHz 10 Kg/Km
Radiated RF immunity, IEC 61000-4-3 with 200 Hz 50% pulse 100% AM at 900 MHz 10 Kg/Km
Shock, non-operating, IEC 60068-2-27 (test Ea, unpackaged shock) 30 g
Shock, operating, IEC 60068-2-27 (test Ea, unpackaged shock) 20 g
Surge transient immunity, IEC 61000-4-5, line-earth (CM) on Ethernet ports ±2 kV
Temperature, operating, IEC 60068-2-1 (test Ad, operating, cold) -40 °C
Temperature, operating, IEC 60068-2-14 (test Nb, operating, thermal shock) -40 °C
Temperature, operating, IEC 60068-2-2 (test Bd, operating, dry heat) -40 °C
Selectable start times T4
Conducted RF immunity, IEC 61000-4-6 with 1 kHz sine-wave 80% AM from 150 kHz - 80 MHz (rms) 10 V
EFT/B immunity for IEC 61000-4-4 at 2.5 kHz on alarm ports ±4 kV
EFT/B immunity for IEC 61000-4-4 at 2.5 kHz on Ethernet ports ±4 kV
EFT/B immunity for IEC 61000-4-4 at 2.5 kHz on power ports ±4 kV
EFT/B immunity for IEC 61000-4-4 at 5 kHz on power ports ±2 kV
Magnetic field immunity, IEC 61000-4-8, long duration at 50 and 60 Hz (A/m) 30
Magnetic field immunity, IEC 61000-4-8, short duration at 50 and 60 Hz (A/m) 300
Radiated RF immunity, IEC 61000-4-3 with 1 kHz sine-wave 80% AM from 80 - 1000 MHz 20 Kg/Km
Radiated RF immunity, IEC 61000-4-3 with 200 Hz 50% pulse 100% AM at 1890 MHz 10 Kg/Km
Relative humidity, IEC 60068-2-30 (test Db, unpackaged damp heat), non-condensing 5 %
Surge transient immunity, IEC 61000-4-5, line-earth (CM) on alarm ports ±2 kV
Surge transient immunity, IEC 61000-4-5, line-earth (CM) on power ports ±2 kV
Surge transient immunity, IEC 61000-4-5, line-line (DM) on alarm ports ±1 kV
Surge transient immunity, IEC 61000-4-5, line-line (DM) on power ports ±1 kV
Temperature, non-operating, IEC 60068-2-1 (test Ab, unpackaged non-operating cold) -40 °C
Temperature, non-operating, IEC 60068-2-14 (test Na, unpackaged non-operating thermal shock) -40 °C
Temperature, non-operating, IEC 60068-2-2 (test Bb, unpackaged non-operating dry heat) -40 °C
Vibration, IEC 60068-2-6 (test Fc, operating) at 10 - 500 Hz 2 g
Voltage variation IEC 61000-4-29, interruption on DC supply ports 10 ms
