1762-IR4 ALLEN BRADLEY MicroLogix 4 Point Module

Allen Bradley 1762-IR4 MicroLogix Expansion I/O PLC, Input Output Module

Be the first to review this product

Manufacturer: Allen-Bradley

SKU: NSRN553

Old price: 7,500.00 (SAR)

Price: 6,955.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Electrical

Number of analogue inputs	4
Input, current	No
Input, voltage	No
Input, resistor	Yes
Input, resistance thermometer	No
Input, thermocouple	No
Input signal, configurable	Yes
Output, current	No
Output, voltage	No
Output signal configurable	No
Analogue inputs configurable	No
Analogue outputs configurable	No
Type of electric connection	Screw connection
Open-circuit detection time	6 ms
Channel to channel isolation	±10V DC
Input type	604 Ω Nickel-Iron 518
Bus current draw	50 mA @ 24V DC, maximum
Fast transient burst	IEC1000-4-4: 2kV, 5 kHz
Update time	Input filter and configuration dependent (typical)
Normal mode rejection ratio	70 dB minimum @ 60 Hz with the 10 or 60 Hz filter selected
Conducted immunity	IEC 1000-4-6: 10 V/m, 80...1000 MHz, 80% amplitude modulation, +900 MHz keyed carrier
Radiated immunity	IEC 61000-4-3: 10 V/m, 80...1000 MHz, 80% amplitude modulation, +900 MHz keyed carrier
Calibration	The module performs autocalibration on channel enable and on a configuration change between channels. You can also program the module to calibrate every five minutes
Typical accuracy	At 25 ° C (77 °F) ambient with module operating temperature at 25 °C (77 °F)
Resolution	Input filter and configuration dependent
Suitable for safety functions	No
Overload at input terminals	Maximum @ ±35V DC continuous
Surge immunity	IEC1000-4-5: 1kV galvanic gun
Module power LED	ON: indicates power is applied
Excitation current source	0.5 mA and 1.0 mA selectable per channel
Cable impedance	Maximum @ 25 Ω (operating with >25 Ω will reduce accuracy)
Power supply distance rating	6 (the module may not be more than 6 modules away from the system power supply)
Heat dissipation	1.5 total Watts (the Watts per point, plus the minimum Watts, with all points enabled)
Input channel configuration	Via configuration software screen or the user program (by writing a unique bit pattern into the module’s configuration file)
Accuracy drift	At 0...55 °C ±0.026 °C/°C (0.026 °F/°F) for Pt 385, ±0.007 Ω/°C (0.012 Ω/°F) for 150 Ω range, ±0.023 °C/°C (0.023 °F/°F) for Pt 3916, ±0.023 Ω/°C (0.041 Ω/°F) for 500 Ω range, ±0.012 °C/°C (0.012 °F/°F) for Ni, ±0.043 Ω/°C (0.077 Ω/°F) for 1,000 Ω range,

Environmental

Operating temperature	-20 °C
ESD immunity	IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect
Operating altitude	2000 m
Storage temperature	-40 °C
Operating humidity	5...95% noncondensing

Input Specifications

A/D converter type	Delta-Sigma
Common mode rejection	>110 dB at 60 Hz (with 10 or 60 Hz filter)
Input impedance	>10 MΩ
Channel diagnostics	Over or under range or open circuit condition by bit reporting for analog inputs

Output Specifications

Non-linearity	±0.05% (in percent full scale)
Typical overall accuracy	±0.5 °C (°F) for Pt 385

General Specifications

Repeatability	±0.2 ohm for other resistances
Input and output group to system isolation	30V AC/30V DC working voltage type test: 500V AC or 707V DC for 1 minute
