BL13-TDT-P AUTONICS Sensor

Sensing type : Through-beam type Applicable pipe: Using binding band: Ø6 to 13mm, Using protection bracket: Ø12.7mm (1/2 inch) transparent pipe in 1mm thickness (FEP (fluoroplastic) or with equivalent transparency) Standard sensing target : Liquid in a pipe Light source : Infrared LED (950 nm) Response time : Max. 2ms Power supply : 12-24VDC ±10% (ripple P-P: max. 10%) Operation mode : Light ON/Dark on (set by button) Control output : PNP open collector
Manufacturer: Autonics
SKU: NSRN118
1,200.00 (SAR)
503.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Sensing type Through-beam type
Applicable pipe Using binding band: Ø6 to 13mm,
Using protection bracket: Ø12.7mm (1/2 inch) transparent pipe in 1mm thickness (FEP (fluoroplastic) or with equivalent transparency)
Standard sensing target Liquid in a pipe
Light source Infrared LED(950nm)
Response time Max. 2ms
Power supply 12-24VDC  ±10%(ripple P-P: max. 10%)
Current consumption Max. 30mA
Operation mode Light ON/Dark ON(set by button)
Control output PNP open collector
Connection type Cable type(Ø2.5, 1m)
Environment_Ambient illumination Sunlight/Incandescent lamp: Max. 3,000lx for each(received illumination)
Environment_Ambient temperature 10 to 55℃
Protection structure IP64
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Material Case: Polycarbonate
Accessories Binding band: 2, Anti-slip tube: 2
Weight Approx. 50g(approx. 13g)
